Husqvarna TE 510 User Manual

H.31Part. N. 8000 B0148 (02-2008)
ENGINE REASSEMBLY
Reassembly of timing system drive gear and chain
The key for the cam chain sprocket must be installed with the cut end out towards
the drive gear.
Lubricate the cam-chain sprocket and install it on the crankshaft using a drift.
Reassemble the cam drive chain.
Reassemble the flywheel key, the spring and the flywheel.

Husqvarna TE 510 Specifications

General

Transmission	6-speed
Front tire	90/90-21
Rear tire	140/80-18
Dry weight	112 kg
Final Drive	Chain
Front suspension (adjustable)	Yes
Rear suspension (adjustable)	Yes
Front brake disc size	260 mm
Rear brake disc size	220 mm
Engine type	Single cylinder, 4-stroke
Fuel system	Keihin FCR-MX 41
Ignition	Electronic
Cooling system	Liquid cooled
Front suspension	Kayaba 48 mm fork
Front brakes	Single disc
Rear brakes	Single disc
