HUST CNC H2N User Manual

HUST H2N Connection Manual
6 - 32
Table 6-5 Definitions of Output Key Code
R242 Output R242 Output R242 Output
0 0 30 S 60
1 1 31 T 61
2 2 32 U 62
3 3 33 V 63
4 4 34 W 64 INPUT
5 5 35 X 65 INSERT
6 6 36 Y 66 AUTO SEQU.
7 7 37 Z 67 FIND LAST “N”
8 8 38
∕
68 Delete one block
9 9 39 # 69 Delete current program
10
˙
40 70 Delete all programs (*5)
11
—
41 71 MCM parameters reset (*6)
12 A 42 72 Delete current key input signal
13 B 43 73 PAGE-UP
14 C 44 74 PAGE-DOWN
15 D 45 75 CURSOR-UP
16 E 46 76 CURSOR-DOWN
17 F 47 77 Clear variable #1~#9999=0 (*7)
18 G 48 *1 78
Read variables burned into FLASH-ROM
#9000 - #9999 (*8)
19 H 49 *2 79
20 I 50 *3 80
21 J 51 *4 81 Burn program into FLASH-ROM (*9)
22 K 52 82 Burn MCM parameters into LASH-ROM (*10)
23 L 53 83 Burn PLC ladder into FLASH-ROM (*11)
24 M 54 84 Reserved
25 N 55 85 Burn system data into FLASH-ROM (*12)
26 O 56 86
Burn variables into FLASH-ROM
#9000-＃9999 (*13)
27 P 57 87
28 Q 58 88
29 R 59 89
Notes:
*1. R242=48, it means sending a cursor-up signal to MMI (Man Machine Interface).
*2. R242=49, it means sending a cursor-down signal to MMI.
*3. R242=50, it means sending a cursor-left signal to MMI.
*4. R242=51, it means sending a cursor-right signal to MMI.
*5. R242=70, it’s equivalent to single block command “G10 P2000”.
*6. R242=71, it’s equivalent to single block command “G10 P1000”.
*7. R242=77, it’s equivalent to single block command “G10 P2002”.
*8. R242=78, it’s equivalent to single block command “G10 P2200”.
*9. R242=81, it’s equivalent to single block command “G10 P600 L01”.
*10. R242=82, it’s equivalent to single block command “G10 P600 L02”.
*11. R242=83, it’s equivalent to single block command “G10 P600 L03”.
*12. R242=85, it’s equivalent to single block command “G10 P600 L05”.
*13. R242=86, it’s equivalent to single block command “G10 P600 L06”.
