LIST OF V18 STD II NA ELECTRICAL COMPONENTS
Item Code as on
V18 Schematic
Description Part Number
Component
Manufacturer
2CR
Blade motor relay,
plus mounting base.
G2R-2-S
P2RF-08-E
Omron
3CR
Head advance relay,
plus mounting base.
G2R-2-S
P2RF-08-E
Omron
12CR
Head Retract relay,
plus mounting base.
G2R-2-S
P2RF-08-E
Omron
Hyd. Valve
Connector
Hirschmann connector H/927811311 Hirschmann
1FU
Fuse holder
8A Time-delay fuse
USM1
ATDR8
Gould
1 L/S
Head Retract
Limit switch with roller lever XCK L115H7 Telemecanique
2 L/S
Head Advance
Limit switch with roller lever XCK L115H7 Telemecanique
3 L/S
Blade Break
Limit switch with roller lever XCK L115H7 Telemecanique
Fan
Hydraulic component cooling fan
28316
Muffin
Coolant Pump
Coolant pump 1 Phase /120 VAC
2E-NT
Little Giant
Coolant Pump Junction Box
SCEJB442
Selectric
Wire terminal 20-10 AWG
WK4/U
Wieland
Wire terminal 20-8 AWG
WK6/U
Wieland
Double ground terminal 20-8 AWG WK4/D2/2SLU Wieland
Options
9SS-Chip Conveyor
Selector Switch
Black, 2 positions, spring return to center selector switch.
Mounting base with 2 N/O contact blocks.
ZB2 BD5
ZB2 BZ103
Telemecanique
Telemecanique
26SS-Oil Heater
Selector Switch.
Black, 2 positions maintained selector switch.
Mounting base with 1 N/O contact block.
ZB2 BD2
ZB2 BZ102
Telemecanique
Telemecanique
Head Angle Indicator
E. ANG.
5LS
Universal Counter
Angle encoder
Limit switch with punger
CNTR-100
0 550 669
XCK L510
