Page 80
XX
The set tempera-
ture has not been
reached.
•
•
•
•
The unit’s steam generation output limitation
prevents full output.
The unit is being operated at “cylinder full”
(only with electrode steam humidifiers).
Incorrect output estimate.
Phase failure. (external fuse)
•
•
•
•
Check steam generation output
limitation parameter “P1”.
See message Maintenance /
Cylinder Full
Check output data, steam bath in-
sulation and dimensions.
Install fuse.
XX
No visible steam in
the cabin.
•
•
•
Steam bath is too well insulated.
Insufficient air circulation in the steam bath
Excessive heat supply (i.e. from heated
benches)
•
•
•
Provide for removal of heat.
Install exhaust fan or check ex-
haust fan performance.
Reduce ancillary heat supply
XX
Temperature is too
high
• Temperature sensor has not been correctly
calibrated.
• Check Parameter “Adjustment
Actual Temperature Value” (G0)
Essence delivery
into the steam bath
is absent or insuffi-
cient
• No essence in reservoir. • Replenish essence.
• Essence injector has not been activated. • Activate essence injector. (Check
power supply to the essence sole-
noid valve and peristaltic pump.)
XX • Essence delivery duration is too short. • Increase essence delivery dura-
tion.
• Essence delivery interval is too long. • Shorten essence delivery interval.
• Fuse or relay in the control for essence
delivery is faulty (when employing 24 V).
• Replace fuse. (Check power supply
to the essence solenoid valve.)
• Tube in peristaltic pump is defective (essence
flows back into the essence reservoir through
the return line).
• Replace tube into peristaltic pump.
XX
Excessive es-
sence delivery into
the steam bath
• Essence delivery duration is too long • Reduce essence delivery duration.
• Essence delivery interval is too short. • Lengthen essence delivery interval.
HL ***
Hy,C***
Possible Condi-
tions
Probable Cause for fault situation Resolution
