Page 25
The jumper is referred to as “open” if there is no plug on either
pin or if only one of the pins is covered.
Change jumper settings only when the system is turned off.
Otherwise, the control could be damaged or unpredictable func-
tioning could occur.
The jumper strip JP1 has 12 jumper positions, designated by the
letters A to L.
JP1
