Page 35
*Only for Operating Mode (U6): external controller
** Minimum output of control signal.
The steam humidifier normally switches to “no demand” mode
with a (control) signal of less than 20%, i.e. no steam is pro-
duced.With a minimum signal of 20%, the humidification output
is 5% of the maximum output of humidifiers of the HeaterLine
type, but 10% of the maximum output of electrode steam humid-
ifiers (HyLine, CompactLine, MiniSteam). Below that level, the
unit turns off.
At lower levels of steam output, the steam accumulates in the
cylinder or steam hose as condensate
, failing to reach its intended
location.
5.1.3 Manual Flush
To drain the steam cylinder manually, follow the steps below:
press and for longer than 5 seconds.
External signals for Comfort / Comfort
Plus (E3)
0(2) - 5 V DC min. 0,1 mA**
0(2) - 10 V DC min. 0,2 mA**
0(4) - 20 V DC min. 0,3 mA**
0(2) - 10 mA DC min. 1,8 V**
0(4) - 20 mA DC min. 3 V**
0 - 140 Ohm*
