HygroMatik Basic - Readout Mode

Page 44
7.2 Readout Mode
Using or , you can toggle between the readout values
(L x) below:
*Only when PI software controller is activated.
Normally the display shows the operational conditions of the
humidifier and a readout value. The readout value is selected as
in the example below:
Example: The standard display should show the “actual value
relative humidity” (L7):
» With or select the actual relative humidity
value
» Confirm selection with
7.2.1 Direct Entry of a Desired Value in Readout Mode
In readout mode, readout values can be displayed but not modi-
fied. Access with modification is possible for frequently adjusted
values.
If the unit is turned off, modifications to desired values in readout
mode are lost.
Example: The steam generation output limitation value should
be reduced from 100% to 50%:
press or until Readout Parameter L5 appears on the
display
Readout
L15 Y1 (solenoid valve) operation cycles
L14 K1 (main contactor) operation cycles
L13 Operating hours counter [dddd:hh]
L12 Output signal [%]
L7* Actual value relative humidity [% RH]
L6* Desired value relative humidity [% RH]
L5 steam generation output limitation [%max.output]
L4 Demand [%]
L3 Internal control signal [%max.output]
L2 actual current value [A]
L1 steam output [kg/h]
L0
total steam [10
3
kg]
L5 steam generation output limitation
L6* desired value relative humidity
* Only when using an PI-controller
Please note
Humidification
Act. value RH
L7 = 62%
menu
Please note
