12. Technical Specifications
*Other voltages upon request.
Heater Element Steam Humidifier
Type HeaterLine HL06 HL09 HL12 HL18 HL24 HL27 HL30 HL36 HL45
Steam Output [kg/h] 6 9 12 18 24 27 30 36 45
Power Rating [kW] 4,5 6,8 9,0 13,5 18,0 20,3 22,5 27,0 33,8
Power Consumption [A] 11,3 16,8 19,5 29,3 39,0 29,3 39 58,5 58,5
Circuit Protection [A] 3x16 3x20 3x25 3x35 3x40 3x35 3x40 3x63 3x63
Type HeaterLine HL60 HL70 HL80 HL90
Steam Output [kg/h] 60 72 81 90
Number of units 2 2 2 2
Power Rating [kW] per unit 22,5 27 33,8 33,8
Power Consumption [A]
per unit
39 58,5 58,5 58,5
Circuit Protection [A]
per unit
3x63 3x63 3x63 3x63
Electrical Connection*
per unit
400V/3/N 50-60Hz
Control Voltage 230V/50-60Hz
Heater Element Steam Humidifier
Type Heater-
Compact (Kit)
HC02
(Kit)
HC03
(Kit)
HC06
(Kit)
HC06
(Kit)
HC09
(Kit)
HC06P HC09P HC12
(Kit)
HC18
(Kit)
HC27
(Kit)
Steam Output
[kg/h]
236696 9121827
Power Rating
[kW]
1,5 2,25 4,5 4,5 6,8 4,5 6,8 9,0 13,5 20,3
Power
Consumption [A]
6,5 9,8 19,6 11,3 16,9 11,3 16,9 19,5 29,3 29,3
Circuit
Protection [A]
1x10 1x10 1x20 3x16 3x20 3x16 3x20 3x25 3x35 3x35
Electrical
Supply*
230V/1/N/
50-60Hz
400V/3/N 50-60Hz
Control Voltage 230V/50-60Hz
