HygroMatik Basic - Electrode Steam Humidifier Specifications

Page 92
*Other voltages upon request.
** 1.3-times power consumption after full blow-down. Note overload capacity of automatic
breakers. If necessary, select the next higher rating.
Electrode Steam Humidifer
Type HyLine HY05 HY08 HY13 HY17 HY23 HY30
Steam Output [kg/h] 5 8 13 17 23 30
Power Rating [kW] 3,8 6,0 9,8 12,8 17,3 22,5
Power Consumption [A] 5,4 8,7 14,1 18,4 24,9 32,5
Circuit Protection [A] 3x6 3x10 3x16 3x20 3x35 3x35
Type HyLine HY45 HY60 HY90 HY116
Steam Output [kg/h] 45 60 90 116
Power Rating [kW] 33,8 2x22,5 2x33,8 2x43,5
Power Consumption [A] 48,8 2x32,5 2x48,8 2x62,8
Circuit Protection [A] ** 3x63 6x35 6x63 6x63
Electrical Connection* 400V/3/N /50-60Hz
Control Voltage 230V/50-60Hz
Electrode Steam Humidifer
Type CompactLine
(Kit)
C01
(Kit)
C02
(Kit)
C06
(Kit)
C10
(Kit)
C17
(Kit)
C22
(Kit)
C30
(Kit)
C45
(Kit)
C58
Steam Output [kg/h] 1 2 6,0 10,0 17,0 22,0 30,0 45,0 58,0
Power Rating [kW] 0,75 1,5 4,5 7,5 12,8 16,5 22,5 33,8 43,5
Power Consumption [A] 3,3 6,5 6,5 10,8 18,4 23,8 32,5 48,8 62,8
Circuit Protection [A] ** 1 x 6 1 x 10 3x10 3x16 3x20 3x35 3x35 3x63 3x63
Electrical Connection* 230V/1/N/
50-60Hz
400V/3/N/50-60Hz
Control Voltage 230V/50-60Hz
Electrode Steam Humidifer
Type MiniSteam MS05 MS05 MS10
Steam Output [kg/h] 4,8 5 10
Power Rating [kW] 3,6 3,8 7,5
Power Consumption [A] 15,7 5,4 10,8
Circuit Protection [A] ** 1 x 16 3 x 6 3 x 16
Electrical Connection* 230V/1/N50-60Hz 400V/3/N/50-60Hz
Control Voltage 230V/50-60Hz
