E6** 1. signal relay same options as with
E5, status 2 = factory
set
Parameter Settings/Data
Parameters
010
E7** 2. signal relay same options as with
E5, status 3 = factory
set
Parameter Settings/Data
Parameters
010
E8** 3. signal relay same options as with
E5, status 10 = factory
set
Parameter Settings/Data
Parameters
010
E9** 4. signal relay same options as with
E5, status 17 = factory
set
Parameter Settings/Data
Parameters
010
E17 baud rate interface 9600 / 4800 / 2400 /
1200
Parameter Settings/Data
Parameters
010
E18* offset dehumidifier [ -2 to + 15%] Parameter Settings/Con-
trol Parameters
010
H1
blow-down counter
(partial blow-down)
0 - 255 (filling cycle)
only for Electrode
Steam Humidifier
Parameter Settings/
Blow-Down Parameters
H2 blow-down dura-
tion(partial blow-down)
0-255 [s] only for Elec-
trode Steam Humidifier
Parameter Settings/
Blow-Down Parameters
010
H6 full blow-down Yes (On)
No (Off)
Parameter Settings/
Blow-Down Parameters
010
H11 blow-down counter
(partial blow-down)
0 - 999 kg
only for HeaterLine unit
Parameter Settings/
Blow-Down Parameters
010
H12 blow-down dura-
tion(partial blow-down)
0-255 [s]
only for HeaterLine unit
Parameter Settings/
Blow-Down Parameters
010
P1 steam generation out-
put limitation
25% to 100% Parameter Settings/Con-
trol Parameters
none
P2 quantity of steammain-
tenance interval
0.1 to 25.5 [10³ kg] Parameter Settings/
Maintenance Parameters
010
P3 reset maintenance
interval
Yes / No Parameter Settings/
Maintenance Parameters
010
P4 offset control signal 0 to 100% Parameter Settings/Con-
trol Parameters
010
P5 address 1 - 999 Parameter Settings/ Data
Parameters
none
P7* sensor damping Yes/No Parameter Settings/ Con-
trol Parameters
none
P8* desired value relative
humidity
[% RH] Parameter Settings/ Con-
trol Parameters
010
P11 reset main contactor
interval
Yes / No Parameter Settings/
Maintenance Parameters
010
P15 Parity 8-N-1
8-E-1
Parameter Settings/ Data
Parameters
010
* Only if PI-controller is activated
** Only if optional signal relay PCB is installed
Para-
meter
Designation Possible Settings in Menu/Submenu Access
Code
