Hypertec CIARA ORION HF310-G4 - Connector Functionality

17 | P a g e
= Normal Mode (Default)
= Recovery Mode
BIOS Password Clear
Clear BIOS Password.
= Normal Mode
= Clear BIOS Password
Overclocking Over Voltage Enable
Overclocking voltage jumper.
= Over voltage enabled (Default Mode)
= Clear BIOS Password
ME Update
ME update flash security.
= Enable ME Flash security
= Disabled ME flash security
NCSI Switch
Onboard LAN or OCP cards switch.
= Onboard LAN (i350) NCSI (default)
= OCP LAN card NCSI
7.3 Connector Functionality
Item
Connector
Description
1
COM 1
COM1 connector
2
OCP PCIe 3.0 x8
Network or RAID OCP card connector
4
PCIE_2 PCIe 3.0 x16
Network or Mega RAID card connector
5
TPM
Trusted Platform Module
6
IPMB
Intelligent Platform Management Bus
12
4x SATA III (SFF-8654)
SATA connector
14
Backplane Panel Header
Backplane Panel connector
15
Front Panel Header
Front Panel connector
19
PMBUS Header
Power Management Bus
22
M.2 Port 1
M.2 connector
23
U.2 Port
U.2 Connector
25
M.2 Port 2
M.2 connector
37
PCIE_1 PCIe 3.0 x16
Network Card
39
Q Code Header
Q Code Connector
40
VGA Port
VGA Connector
