20. Rack Mounting
This section provides information on how to mount a system into the rack with the rack rails.
Step 1. Install rails into the rack
Step 2. Pull the middle fully extended member in lock position; ensure that the ball bearing retainer is located at the front of the middle member. Horizontally install
chassis half way into slide member.
Pull Lever
and Push
Rail until
Click
Push until
Click
