Hypertec CIARA ORION HF310-G4 - Replacing Fixed SSD

29 | P a g e
18. Replacing Fixed SSD
This section provides information on how to replace the fixed 2.5-inch SSD in the Orion HF310-G4 system.
Step 1: Remove the SATA and power cables. Then, turn thumbscrews anticlockwise to unscrew with Philips screwdriver type 2.
Step 2: Unscrew these screws as illustrated below.
Note: To access the lower hard drive, the top hard drive needs to be removed first.
1
2
