Hypertec CIARA ORION HF310-G4 - Page 33

32 | P a g e
1. Step 3: Carefully lift the riser card bracket by tilting it, and slide the riser card bracket out of the rear panel. Please ensure that the cables connected to the
motherboard are not disconnected.
Step 4: Once the GPU cable connectors are out, proceed to slowly slide out the GPU.
2
1
3
1
2
