MAI
NTE
NANCE
H
P
R13
0 Manual Gas
Instruction Manual
5-35
6
TP 206
TP 210
T
esting the flow switch
1.
T
urn O
N the power
.
2.
Measure the VD
C between TP210 and TP206.
TP206 is common on P
C
B3. TP210 provides a filtered, 6
7% scaled, volt
age from the flow switch. 0.45 VDC (0.6
7
VDC at the flow switch) equals 2.3 lpm (0.6 gpm). If the TP210 voltage reading is below 0.45 VD
C and the flow is
equal to or above 3.0 lpm (1 gpm), replace the flow switch.
157
159
