Hypertherm HPR130 User Manual

INSTALLATION
HPR130 Manual Gas Instruction Manual 3-5
System components
Power supply
Ignition console
Gas console
Off-valve assembly
Torch
Cables and hoses
Pilot arc lead
Negative lead
Ignition console power cable
Ignition console coolant hoses
Gas control cable
Gas power cable
Gas console to off-valve hose and lead assembly
CNC interface cable
Optional CNC interface cable for systems with multiple power supplies
Torch lead assembly
Work lead
Supply gas hoses
Oxygen
Nitrogen
Air
H35 or F5
Customer-supplied power cable
Main power cable
B
12
13
14
15
16
11
E
10
9
8
7
6
5
4
C
D
3
2
1
A
6
