6
PARTS LIST
HPR130 Manual Gas Instruction Manual 6-13
Recommended spare parts
Power supply
Part
Number Description Designator Qty.
129633 Green power lamp assembly 1
027634 Filter housing 1
027664 Filter element 1
129792 Chopper assembly CH1 1
127039 6" fan :230 CFM, 115 VAC 50-60 HZ 1
027079 10" fan :450-550 CFM, 120 VAC 50-60 HZ 1
003149 Relay: pilot arc, 120 VAC CR1 1
041837 PCB: I/O 1
003139 Contactor CON1 1
109004 Current sensor: hall 100 amp, 4 volt 1
129791 Start circuit assembly PCB1 1
108263 Fuse: 175 amp, 250 volt F3 1
008551* Fuse: 7.5 amp, 600 volt F1, F2 2
041909 Control PCB PCB3 1
041802 Power distribution PCB PCB2 1
129793 Flow switch assembly FLS 1
027185 Heat exchanger fan: 4" 1
006075 Check valve: 1/4" FPT 1
129995 Solenoid valve assembly CLT SOL 1
129994 Pump assembly: 70 gpm, 200 psi 1
031113 Motor: 1/3 HP, 240 volt, 50-60 HZ 1
* 400, 480 and 600 volt power supplies
Ignition console
Part
Number Description Designator Qty.
041817 HFHV Ignition PCB 1
129854 Transformer T1 1
Gas console
Part
Number Description Designator Qty.
041805 Power distribution PCB PCB1 1
041822 Valve driver PCB PCB3 1
005263 Pressure sensor PT1-PT3 1
006109 Solenoid valve SV1-SV14 2
005262 Illuminated power switch SW1 1
Off-valve
Part
Number Description Designator Qty.
006109 Solenoid valve V16-V19 1
