I
N
ST
ALLA
TI
ON
H
P
R13
0 Manual Gas
Instruction Manual
3-27
6
Examples of input circuits
Output from
CNC/PL
C
External relay
(AC or DC)
1. Relay interface
+24 VDC
HPR
Pow
e
r
ground
2. Optocoupler interface
CNC/PL
C
+24 VDC
HPR
Pow
e
r
ground
T
ransistor-output
optocoupler
12V-24VDC
CNC/PL
C
+24 VDC
HPR
Pow
e
r
ground
Power
ground
Active-high drive
3. Amplified-output interface
Note:
The external relay's life may be improved by adding a
metallized-polyester capacitor (0.022µF 100V or higher) in
parallel with the relay contacts.
74
76
