OPERATION
4-18 HPR400XD Manual Gas Instruction Manual
Cut charts
The following Cut charts show the consumable parts, cutting speeds and the gas and torch settings required for each
process.
The numbers shown in the Cut charts are recommended to provide high-quality cuts with minimal dross. Because of
differences between installations and material composition, adjustments may be required to obtain desired results.
Bevel cut charts
The bevel cut charts are slightly different from the standard cut charts. The torch-to-work distance is a range rather than
a single value, material thickness is given as an equivalent value, a column for minimum clearance has been added, and
there is no column for arc voltage.
Equivalent thicknesses and the arc voltages will vary depending on the angle of the cut. The angle for bevel cutting can
range from 0° to 45°.
See Bevel cutting definitions on the next page for more detailed information.
