SPECIFICATIONS
2-6 HPR400XD Manual Gas Instruction Manual
Cooler – 078531
• The cooling system can contain up to 34.5 liters (9 gallons) of coolant.
• Maximum cable length from the cooler to the power supply is 4.57 meters (15 ft).
• Maximum hose length from the cooler to the ignition console is 76.2 meters (250 ft).
• Allow 1 m (3 ft) of space on all sides of the cooler for ventilation and service.
457 mm
18.00"
895 mm
35.25"
895 mm
35.25"
622 mm
24.50"
76 mm
3.00"
To the filter on
the rear of the
cooler
Weight with no
coolant
75 kg
165 lb
