OPERATION
4-38 HPR400XD Manual Gas Instruction Manual
Metric
English
Select
Gases
Set
Preflow
Set
Cutflow
Minimum
Clearance
Equivalent
Material
Thickness
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma Shield Plasma Shield Plasma Shield mm
mm
mm mm/m mm factor % seconds
H35
N
2
20 40 70 80 2.0
10
4.5 – 10.0
980
7.7 170
0.3
12
820 0.5
15
580 0.8
20
360 1.3
25
260 Edge start
Select
Gases
Set
Preflow
Set
Cutflow
Minimum
Clearance
Equivalent
Material
Thickness
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma Shield Plasma Shield Plasma Shield in
in
in ipm in factor % seconds
H35
N
2
20 40 70 80 0.080
3/8
0.180 – 0.400
40
0.310 170
0.3
1/2
30 0.5
5/8
20 0.8
3/4
15 1.3
1
10 Edge start
Stainless steel bevel cutting
H35 Plasma / N
2
Shield
130 A
Flow rates – lpm/scfh
H35
N
2
Preflow 0 / 0 90 / 190
Cutflow 26 / 54 114 / 240
220738220637 220606220739 220179220656
Note: Bevel angle range is 0° to 45°
220571
Marking
Select
Gases
Set
Preflow
Set
Cutflow
Amperage
Torch-to-Work
Distance
Marking
Speed
Arc
Voltage
Amps
mm in mm/min ipm Volts
N
2
N
2
10 10 10 10
18
2.5 0.10 6350 250 130
ArAir50105010
15
3.0 0.12 2540 100 75
