Operation
4.2.2 Red I/O Status LEDs
The iRIS has 3 red LED indicators that are linked to the digital I/O and can be useful for diagnostic purposes. The LED’s are
active when the corresponding input or output is active (pulled low).
4.2.3 Red Comms Status LED
The iRIS has a further red LED indicator that provides general communication status. It will flash whenever an RS232 or
SDI-12 data packet is transmitted.
Note that the red I/O and comms LED indicators are only active if the unit is running on external power.
4.3 LCD & Keypad
This chapter contains the following subsections:
§
LCD Operation
§
Status Icons
§
Keypad
§
Display Menu Structure
4.3.1 LCD Operation
The iRIS LCD is controlled to optimise power consumption. If the display has powered down, the unit is in a lower power
mode and can be woken by using the keypad.
After a certain period of no key presses, the display and backlight will power down again, although other functions
continue normally. If the user was logged on (PIN entered), they will be logged off. This version of software has the
timeout period set to 60 seconds.
