Introduction
1
Introduction
Thank you for choosing our product. We hope you will enjoy using the device.
HyQuest Solutions manufactures, sells, installs and operates quality instrumentation, data loggers and communication
technology. Products are designed with passion for environmental monitoring and with a deep understanding of the
quality, accuracy and robustness needed to fulfil the requirements of measurement practitioners in the field.
The present User Manual will help you understand, install and deploy the device. If, however, you feel that a particular
information is missing, incomplete or confusing, please do not hesitate to contact us for further support!
The iRIS 150FX is a small, compact datalogger featuring an LCD display and keypad. It can be connected to a wide variety
of sensors, and features two analogue (0 - 5 V, 0 - 20 mA) inputs, two digital inputs, SDI-12 serial instrument support and
a single digital output for alarm or control purposes.
The iRIS 150FX is supplied in a powder-coated die-cast aluminium enclosure. Power supply and I/O connections are
provided by a small screw terminal block within the unit. Cable access is via two NG12 glands on the bottom edge of the
enclosure. A small text/graphics LCD provides the user display and user input is via a four key keypad in the same style as
other iRIS dataloggers.
The iRIS 150FX supports a maximum of six virtual sensors, the sources of which can be chosen from a range of physical
digital or analogue types. Each sensor can be checked for up to six separate alarm conditions, each with separate trigger
and reset levels. Each alarm also has an optional duration, which is used to delay the alarm trigger for analogue inputs
and to determine the time over which pulse input counters should be totalised (rainfall, flow meter pulse etc.). Data is
logged in a four word (8 byte) compressed format which includes full date and time to fractions of a second.
The alarm(s) can be linked to the digital output to activate external equipment when one or more alarms are activated in
the event of alarm activation.
Feature Summary
The iRIS 150FX has the following features:
§
IP65 rating
§
LCD and keypad
§
RS-232 interface
§
6 simultaneous logging channels (virtual sensors)
§
3 auxiliary logging channels for internal measurements
§
2 digital inputs (pulse, frequency, counter)
§
2 analogue inputs (0 - 5 V fixed span – current e.g: 0 - 20 mA with internal resistor enabled)
§
1 digital output (open drain pull-down). A switched supply voltage output is available on iRIS 150FXC.
§
6 alarms. Can be associated with any of the main six logging channels. Can activate the digital output if any alarm is
activated.
§
Internal, replaceable 3.6 V AA size lithium battery backup. Or D size battery option is available.
Typical Applications
The iRIS can be used for a wide range of diverse applications, including but not limited to:
§
Rainfall measurement
§
Water / power / gas metering
§
River level monitoring
§
Wind measurement
§
Mobile temperature monitoring
§
Irrigation monitoring / control
