Operation
4.3.4.1 Log In/Out
The Log-In/Out screen is a special screen that is only available from the Title or Status Screens. It is used to enter a PIN
number which then enables access to restricted screens. It is reached by pressing the Alt and Enter keys simultaneously
from the Title or System Status screens.
If the user is not logged in, the PIN code can be entered. If the user is already logged in, they will be immediately logged
out again. This provides a rapid way of logging out to regain terminal access when the unit is configured for telemetry.
See Section Telemetered Mode for details on telemetered mode.
Increment / decrement PIN number
Multiply PIN number by 10 or accept PIN number as displayed.
Moves back to Title screen
Once the PIN number matches that programmed into the device and the [ENTER] key is pressed, the user will be logged in
and returned to the top-level Welcome (System Status 1) screen. Successful login will also remove the padlock icon from
the top of the display.
4.3.4.2 Title
Metering Software variant
The default “home” screen in the metering software variant shows the flow rate and running totaliser for each enabled
digital input.
Flow 1: 6.7 l/s
Tote 1: 165448 m3
Flow 2: 0.0 l/s
Tote 2: 5288 m3
Standard Software
The first screen to be displayed is the Title screen in the standard software. This basic screen shows the unit name, serial
number, comms address as well as the current time and date.
Demo
iRIS150FX AG3-0001
Adr:1
08:37:46
01 Feb 2014
This screen appears as a second screen in the metering version.
