S LIDE S MART DC S PECIFICATIONS
Copyright Notice
© Copyright 2012 by HySecurity Gate Inc.
All rights reserved. No part of this manual may be reproduced by any means (photocopier, electronic, or mechanical), without the express
written permission of HySecurity Gate Inc. Federal Copyright law prohibits the reproduction, distribution, or public display of copyrighted
materials without the express written permission of the copyright owner, unless fair use or other exemption under copyright law applies.
Additionally, HySecurity Gate Inc. makes no representations or warranty with respect to this manual. We also reserve the right to make
changes in the products described without notice and without any obligation to notify any persons of any such revision or change.
Trademarks
SlideSmart, Smart DC Controller, S.T.A.R.T. and the HySecurity logo are trademarks or registered trademarks of HySecurity Gate, Inc.
Publication Information
Published in the United States of America. June 22, 2012 Document Number: D0337 Revision D
Model SlideSmart DC 15 SlideSmart DC 10F SlideSmart Solar
Max. Gate Length 40 ft (12.2m) 40 ft (12.2m) 40 ft (12.2m)
Max. Gate Weight 1,500lbs (680kg)
1000lbs (453kg)
DCS 15 = 1,500lbs (680kg)
DCS 10F = 1,000lbs (454kg)
Gate Speed
1ft/s, 1. 25 for Usage Class III & IV 2ft/s, 2.25 for Usage Class III & IV
1ft/s and 2ft/s, respectively
UPS Operation on
Batteries only
Up to 4,000ft of gate travel
(1,219m)
Up to 4,000ft of gate travel
(1,219m)
Up to 1,500ft (457m) of gate
travel per day (8Ah batteries fully-
charged)
Duty Cycle Continuous Continuous Continuous
Power: Single phase
(switch selectable)
115 volts, 3 amps, 50/60 Hertz
230 volts, 1.5 amps, 50/60 Hertz
115 volts, 3 amps, 50/60 Hertz
230 volts, 1.5 amps, 50/60 Hertz
Solar-powered (24VDC, two
20 WATT panels) 70 cycles/day
in a full sun for 3 hours
Horsepower ½ hp ½ hp ½ hp
Accessory Power 1 amp each at 12VDC, 24VDC,
and 24VAC
1 amp each at 12VDC, 24VDC,
and 24VAC
1 amp each at 12VDC and
24VDC
Two Programmable
User Relays
250VAC, 10A
30VDC, 3A
250VAC, 10A
30VDC, 3A
250VAC, 10A
30VDC, 3A
Communication USB, RS232, RS485 USB, RS232, RS485 USB, RS232, RS485
Te m pe ra tur e R at in g -13°F to 158°F (-25°C to 70°C) -13°F to 158°F (-25°C to 70°C) -13°F to 158°F (-25°C to 70°C)
Certification 500,000 cycles 500,000 cycles 500,000 cycles
DC Batteries Two 8Ah (50Ah - optional) Two 8Ah (50Ah - optional) Two 8Ah (50Ah - optional)
Est. Shipping Weight 160 lbs. (73 kg) 160 lbs. (73 kg) 150 lbs. (68)
UL Listing Class I, II, III, IV Class III, IV DCS 15 = Class I, II, III, IV
DCS 10F = Class III, IV
Limited Warranty 5 years commercial use (7 years
for single-family residence)
5 years commercial use 5 years commercial use (7 years
for single-family residence)
