HySecurity SlideSmart DCS 15 - Chapter 4: Smart DC Controller; Smart DC Controller

Revision D Smart DC Controller 4-1
Smart DC Controller
Chapter 4
This section provides information about the Smart DC Controller board; its inputs for peripheral connections
and its monitoring capabilities. This section explains how to:
1. Make connections on the Smart DC Controller
2. Connect Vehicle Detectors
3. Connect Accessory Devices
• Entrapment Sensor
Connections
•Access Controls
• Manual Push-button Station
•User Relays
Figure 4-1.
