HySecurity SlideSmart DCS 15 User Manual

Site Overview & Planning
Revision D Installation 1-5
Rear Installation
A rear installation requires additional idler wheels and gate brackets, but it provides aesthetics as the chain is
not visible along the gate.
Le Hand Gate
opening
Idler Post
Posion post to maintain a minimum
distance of 1 foot (31 cm) from the end
of the gate when gate is fully closed.
End of the gate
o
s
t
I
d
l
er
Po
p
o
P
os
i
on
a
te
8"
5"
OPEN
OPEN
Gate
Side View
Concrete pad
Chain to Gate
Ideal distance = 3¾" (9.5cm)
Min. distance = 2½" (6.4cm)
7 ¾"
(19.7cm)
Chain
height
Lengthen the chain
access slot by cung
the cover on the
chain side only.
17 ½"
(44.5cm)
8 "
(20.3cm)
View shows how to feed chain over
sprocket and idler wheel for a
Sprocket
Chain
Idler wheel
Target
magnet
Figure 1-7.
Target magnet position between idler wheel and sprocket when gate is fully closed.
rear installation.
Chain & bracket position:
8" (20cm) and 5" (13cm)
