HySecurity SlideSmart DCS 15 User Manual

SlideSmart Components
Revision D Intro-1
S LIDE S MART C OMPONENTS
Service Outlet
115VAC, 15A
O
DC
POW
OF
O
AC
POW
OF
Cover
Motor
Gearbox
Sprocket
Idler, 2x
Control Box
Board, Smart
DC Controller
Buzzer
Switch, Reset
Emergency
Stop button
Battery kit, 8Ah
Cover, Latch
DC Switch,
On/Off
AC Switch,
On/Off
Circuit
Breaker
115VAC
Service
Outlet
Board, Power supply
Pulley, Gearbox
Belt Drive, 2ft/s
Protection plate &
Cover
Transformer
Pulley, Motor
Serial # location
Pulley, Gearbox
Belt drive, 1ft/s
Brush kit
WARNING Label
Target sensor (2x)
Base plate
Board, Power supply
30 ft of #40 chain,
bracket & hardware
Note: Refer to Parts & Limited Warranty for SlideSmart parts list.
