Hytera PD78XG Service Manual

Service Manual UHF1 (400-470MHz) Information
107
No. Ref. No. Print No. Part No. Description
881 R9096 T3F 3001053320000 3.3KΩ
882 R9097 T2F 3001053320000 3.3KΩ
883 R9098 T2F 3001053320000 3.3KΩ
884 R9099 T4D 3217105010000 1nH
885 RN242 T3J 3005051030010 10KΩ
886 RN243 B4I 3005051030010 10KΩ
887 RN255 B3K 3005060000000 0Ω
888 RN256 B3K 3005051030010 10KΩ
889 RN257 T4J 3005061010000 100Ω
890 RN258 T4I 3005061010000 100Ω
891 RN259 T3J 3005060000000 0Ω
892 RN260 T2J 3005061010000 100Ω
893 RN261 B4K 3001052230020 22K*2
894 RN401 T4I 3005060000000 0Ω
895 T9001 T4E 5406000000200 Transformer
896 T9002 T4F 5406000000200 Transformer
897 U101 B1I 3616059000000 Switch IC
898 U102 B1I 3605002057290 Operational amplifier
899 U103 T1I 3604019000000 PLL IC
900 U104 B1I 3616059000000 Switch IC
901 U201 B3I 3610010000010 MCU OMAP5912ZZG
