Hytera PD78XG Service Manual

Service Manual VHF (136-174MHz) Information
429
11.7 Parts List
PD70X/ PD70XG/ PD78X/ PD78XG/ HD705/ HD705G/ HD785/ HD785G Main Board
No. Ref. No. Print No. Part No. Description
1 ANT1 T2B 6201847000000 Antenna spring plate
2 C100 T1G 3101058200000 82PF
3 C101 B1F 3101054710010 470PF
4 C102 B1G 3101051040060 0.1UF
5 C103 B1G 3101051020010 1000PF
6 C104 T1F 3101051020010 1000PF
7 C105 B1I 3101051040060 0.1UF
8 C107 T1F 3101051000020 10PF
9 C108 T1G 3101051020010 1000PF
10 C109 T2G 3101051800010 18PF
11 C110 B2G 3101053310030 330PF
12 C111 T1F 3101050700010 7PF
13 C112 T1F 3101050700010 7PF
14 C114 T1F 3101050500010 5PF
15 C115 T2F 3101050500010 5PF
16 C116 T1F 3101051000020 10PF
17 C117 T1G 3101051040060 0.1UF
18 C118 T1G 3101051020010 1000PF
19 C119 B2G 3101053300000 33PF
