Hytera PD78XG Service Manual

UHF2 (450-520MHz) Information Service Manual
154
8.7 Parts List
PD70X/ PD70XG/ PD78X/ PD78XG/ HD705/ HD705G/ HD785/ HD785G Main Board
No. Ref. No. Print No. Part No. Description
1 ANT1 T2B 6201847000000 Antenna spring plate
2 C101 B1F 3101054710010 470PF
3 C102 B2H 3101054790010 4.7PF
4 C103 B2H 3101054790010 4.7PF
5 C104 T1G 3101054710010 470PF
6 C105 B1I 3101051040060 0.1UF
7 C106 B2G 3101050500010 5PF
8 C107 T1F 3101050800000 8PF
9 C108 B2H 3101050500010 5PF
10 C109 B2H 3101050500010 5PF
11 C110 B2H 3101051000020 10PF
12 C111 T1F 3101054790010 4.7PF
13 C112 T1F 3101054790010 4.7PF
14 C114 T1F 3101050500010 5PF
15 C115 T2F 3101050500010 5PF
16 C116 T1F 3101051000020 10PF
17 C117 T1G 3101051040060 0.1UF
18 C118 T1G 3101054710010 470PF
19 C119 T1G 3101050800000 8PF
