Hytera PD78XG Service Manual

UHF5 (806-941MHz) Information Service Manual
334
10.7 Parts List
PD70X/ PD70XG/ PD78X/ PD78XG/ HD705/ HD705G/ HD785/ HD785G Main Board
No. Ref. No. Print No. Part No. Description
1 ANT1 T2A 6201847000000 Antenna spring plate
2 B / 6201915000000 Shielding can for antenna spring plate
3 C / 6201935000000 Shielding can for switching power
4 C101 B1F 3101054710010 470pF
5 C102 B1G 3101051040060 0.1uF
6 C103 B1G 3101055600000 56pF
7 C104 T2F 3101055600000 100pF
8 C105 B1I 3101051040060 0.1uF
9 C106 B2G 3101051040060 0.1uF
10 C107 T2F 3101051000020 10pF
11 C108 T1F 3101055600000 100pF
12 C109 B1G 3101051040060 0.1uF
13 C111 T2F 3101052290020 2.2pF
14 C115 T1F 3101053690000 3.6pF
15 C116 T2E 3101050300020 3pF
16 C117 T1G 3101051040060 0.1uF
17 C118 T1G 3101055600000 56pF
18 C119 T2E 3101050600010 6pF
19 C120 T1G 3101055600000 56pF
