Hytera PD78XG Service Manual

Baseband Section Service Manual
18
3.5 PCB Difference
For UHF1 PCB, Version H and Version K are made on the basis of Version F.
 The following changes are made for Version H:
 Remove the board border and the small board.
 C802 is compatible with 1206 and 0805.
 The following changes are made for Version K:
 Add test points (P609 and P610) for the GPS power supply.
 Add capacitors C301, C302, C303, C304 and C305.
 Add R208.
 Remove the board border.
 C802 is compatible with 1206 and 0805.
For VHF PCB, Version B is made on the basis of Version A. However, some changes are made for
Version B:
 Add test points (P609 and P610) for the GPS power supply.
 Add R208.
 C802 is compatible with 1206 and 0805.
