Hytera PD78XG Service Manual

UHF3 (350-400MHz) Information Service Manual
244
9.7 Parts List
PD70X/ PD70XG/ PD78X/ PD78XG/ HD705/ HD705G/ HD785/ HD785G Main Board
No. Ref. No. Print No. Part No. Description
1 ANT1 T2B 6201847000000 Antenna spring plate
2 C101 B1F 3101054710010 470PF
3 C102 B2H 3101050400010 4PF
4 C103 B2H 3101050400010 4PF
5 C104 T1G 3101054710010 470PF
6 C105 B1I 3101051040060 0.1UF
7 C106 B2G 3101050600010 6PF
8 C107 T1F 3101050800000 8PF
9 C108 B2H 3101050800000 8PF
10 C109 B2H 3101050800000 8PF
11 C110 B2H 3101051200020 12PF
12 C111 T1F 3101054790040 4.7PF
13 C112 T1F 3101054790040 4.7PF
14 C113 T1G 3101051200020 12PF
15 C114 T1F 3101050800000 8PF
16 C115 T2F 3101050800000 8PF
17 C116 T1F 3101051200020 12PF
18 C117 T1G 3101051040060 0.1UF
19 C118 T1G 3101054710010 470PF
