Hytera PD78XG Service Manual

Service Manual UHF2 (450-520MHz) Information
187
No. Ref. No. Print No. Part No. Description
692 Q9007 B1F 3403008000010 BRT
693 Q9008 B1F 3403008000010 BRT
694 Q9017 B3G 3404006000000 NPN transistor
695 Q9018 B3G 3404006000000 NPN transistor
696 Q9019 B2F 3403999000000 Compound transistor
697 Q9020 B1E 3403999000000 Compound transistor
698 Q9021 B2F 3401001000490 PNP transistor
699 R101 T2G 3001055600000 56Ω
700 R102 T1G 3001051030000 10KΩ
701 R103 T1G 3001051000000 10Ω
702 R104 T2F 3001051020000 1KΩ
703 R105 B1I 3001051030000 10KΩ
704 R106 T1G 3001055620000 5.6KΩ
705 R107 B1G 3001053310000 330Ω
706 R108 T1G 3001053320000 3.3KΩ
707 R109 B1I 3001051040000 100KΩ
708 R110 T1G 3001058220000 8.2KΩ
709 R111 T1G 3001051010000 100Ω
710 R112 T2G 3001051840000 180KΩ
711 R113 T2G 3001054710000 470Ω
712 R114 T2G 3001053320000 3.3KΩ
