Hytera PD78XG Service Manual

UHF3 (350-400MHz) Information Service Manual
292
No. Ref. No. Part No. Description
24 Q1001 3403009000010 Compound transistor
25 U1001 3805000000040 EMI filter
26 J1001 5201016100040 Board-to-board connector
27 S1003 4301080000020 Momentary contact switch
28 / 41PD7002002B0 PCB
29 R1001 3001056810000 680Ω
30 C1015 3101051040060 0.1UF
31 C1016 3101051040060 0.1UF
32 C1017 3101051040060 0.1UF
33 L1001 3221506181000 Bead
34 U1002 3608006000030 Power management IC
PD78X/ PD78XG/ HD785/ HD785G Channel Board
No. Ref. No. Part No. Description
1 R1002 3001051210010 120Ω
2 C1001 3101052710000 270PF
3 C1002 3101052710000 270PF
4 C1003 3101052710000 270PF
5 C1004 3101052710000 270PF
6 C1005 3101052710000 270PF
7 C1006 3101052710000 270PF
8 C1007 3101052710000 270PF
9 C1010 3101052710000 270PF
10 C1011 3101052710000 270PF

Hytera PD78XG Specifications

General

Brand	Hytera
Model	PD78XG
Category	Portable Radio
Language	English
