Hytera PD78XG Service Manual

Service Manual GPS Circuit
21
No. Ref. No. Print No. Part No. Description
11 C522 B3C 3101051040060 0.1U
12 C523 B2C 3101051040060 0.1UF
13 C524 B2C 3101055600000 56P
14 C525 B2C 3101051040060 0.1UF
15 C526 B2C 3101051050000 1UF
16 C527 B2C 3101050200010 1.2P
17 C529 B2B 3101053000010 Chip capacitor 30P
18 L501 B2C 3297106339000 3.3nH
19 L502 B3C 322150660108 Bead
20 L503 B2C 3297106339000 3.3nH
21 L504 B2C 3297106339000 3.3nH
22 L505 B2C 322150660108 Bead
23 L506 B3C 3210106390000 39nH
24 L507 B3C 3210305180000 18nH
25 L508 B3C 3210305829000 8.2nH
26 L509 B3C 3210305829000 8.2nH
27 L9034 B2C 3210105100000 Multi-layer chip inductor 10nH
28 R501 B3C 3001054710000 470Ώ
29 R502 B3C 3001053310000 330Ώ
30 R503 B4D 3001051010000 100Ώ
31 R504 B3C 3001051030050 10KΏ
