Service Manual 13BExploded View
491
No. Part Number Description Qty.
5 6001068000010 Channel selector knob 1
6 6100502000000 Emergency key 1
7 7209002501000 Nut for antenna 1
8 7206002500200 Nut for volume switch 1
9 / Channel board 1
10 7207002201000 Nut for encoder switch 1
11 7000218000000 Stud 2
12 1300PD7000090 FPC 1
13 7102003500210 Machine screw 11
14 / Semi-finished main board 1
15 6201848000000 Motor fixing sheet 1
16 5402000000060 Motor connector 1
17 4400000048000 SMA RF connector 1
18 6001070000000 Rear cover 1
19 6100505000000 Waterproof ring for battery connector 1
20 6100503000000 Waterproof ring for radio 1
21 6100527100000 Waterproof ring for machine screw 4
22 7102009000020 Machine screw 2
23 7101904020300 Self-tapping screw 2
24 6300116001000 Aluminum chassis 1
25 6100111000010 Silicone rubber MIC cover 1
26 6201870000000 Speaker fixing sheet 1
27 5001210000400 Speaker 1
28 6000787000000 PTT key cover 1
To Next Page
