22
Sockets
Sockets
There are different types of heavy-duty sockets to use with the tool:
1. 6-point sockets / 12-point sockets (regular / high)
2. 6-point Allen sockets / 12-point Allen sockets(regular / high)
3. Eccentric sockets
4. Customized sockets
The heavy-duty sockets are available in the sizes ½, ¾, 1, 1½, 2½ and 3½.
Warning:
• Do not use sockets that are used on impact wrenches.
Securing the socket (type 1)
1.
Slide the securing pin (B) into the socket
(A) as shown.
2. Fit the rubber ring (C) to the socket (A) as
shown.
Securing the sockets (type 2)
1.
Fit the securing clip (B) to the socket (A)
as shown.
6
6.1
6.2
