28
1. Turn the pressure control valve (A) clockwise to
set the maximum pressure (10,000 psi, 700 bar).
If you use Allen sockets, there are restrictions to
make sure that the sockets do not break.
2. Place the tool onto the nut or the bolt correctly.
Refer to the marking “LOOSEN” on the tool.
3.
Press and hold the start button (B) on the remote
control until the square drive no longer turns. The
piston in the tool is in the fully extended position.
An audible click will sound. The pressure gauge
increases to the set value.
4.
Release the start button (B) on the remote control.
The piston in the tool moves to the fully retracted
position. An audible click will sound.
5. Repeat steps 3 and 4 until you can loosen the
nut or the bolt by hand.
Automatic shutoff system
The electric pump unit is equipped with an automatic shutoff system. The pump unit will be switched
off after approximately 30 seconds of non-operation to prevent wear and overheating. To restart
the pump unit, press the start button on the remote control.
Thermal protection
The electric pump unit is equipped with a thermal protection to monitor the temperature of the motor.
If the preset maximum temperature is exceeded, the pump will be switched off automatically and
the green LED indicator on the pump unit will turn off.
The green LED indicator on the pump will turn on when the motor has cooled down.
The pump unit is ready to operate.
7.7
7.8
Operation (Cont’d.)
