23
Operation
Operation
Check the following items before each use:
• Oil level in the oil tank is between the minimum mark and the maximum mark.
• Power supply is correct.
• Power cable is fully unrolled and not kinked, twisted, or damaged.
• Remote control cable is fully unrolled and not kinked, twisted or damaged.
• All couplings and other connections are tight and not damaged or deformed.
•
Hydraulic hoses are securely connected, not kinked, twisted, or damaged. Inspect the hydraulic
hoses for damage with a set pressure of 2,900 psi (200 bar), 5,800 psi (400 bar) and 10,000
psi (700 bar) respectively.
• All moving parts of the tool are clean and sufficiently lubricated with a high-quality NLGI #2
molybdenum disulfide grease.
• Square drive and the drive retainer are securely fitted.
• Reaction arm is placed against a solid reaction point and secured to the tool.
• Socket has the correct size and is secured to the tool.
• All securing clips, securing pins and securing screws are fitted and secured to the pump unit,
hydraulic hoses, the tool, the reaction arm and the socket.
• All water, if present, is drained from the water separator (pneumatic pump units only).
• Pressure gauge does not leak. Signs of leakage are a decrease in the level of glycerin in the
pressure gauge or the pressure gauge filled with hydraulic oil.
Remote control
Electric pump unit
1. Press the start button (A) on the remote control
to switch on the pump unit.
2.
Press and hold the start button (A) on the remote
control to increase the pressure in the pump unit
and operate the tool.
3. Press the stop button (B) on the remote control
to switch off the pump unit.
7
7.2
7.2
7.2.1
