7.
Notes on using cable bearers
● The supplied cables are not robot cables.
Accordingly, never store the cables in a cable bearer.
● Always use a robot cable for
each relay cable.
● Use a cable bearer with a bending radius (r)
of 50mm or greater.
● Do not let the cable get tangled or kinked in a cable bearer or flexible tube. When bundling the cable, keep
a certain degree of flexibility (so that the cable will not become too taut when bent).
● Do not cause the cables to occupy more than
60% of the space in the cable bearer.
● Do not lay signal lines together with circuit
lines that create a strong electric field.
Bending radius (r)
Cable beare
