Appendix · How to use the home mark
How to use the home mark
◆
Please affix these marks to the actuator as home markers as needed.
Appendix
Contents of sticker
Home mark sticke
r
× 1 sheet
Home mark scale × 4 Home mark × 4
(Scale: 1mm graduation mark, 10mm width)
•
Peel off the home marks and use as a base sheet.
Note 1. Every mark has an adhesive back.
2. Remove smears and stains from the surface before affixing the marks.
3. Avoid labels or nameplates as a marking location.
Example of Use
[1] Used as home position
On the slider
Motor
Motor
On the slider
On the base
•
Place the two marks when the actuator is stopped at the home position.
[2] Used as stop positions
A
t stop positions on the base
