Pin Signal
1 Not Connected
2 Transmit
3 Receive
4 DTR (Not connected on 3-wire cable)
5 Signal Ground
6 DSR (Not connected on 3-wire cable)
7 Not Connected
8 RTS
9 Not Connected
See
“Description of models” on page 4 for the cable part number.
RS-232 parameters
Protocol
DTR/DSR mode or XON/XOFF mode. Dip switch selectable.
Baud rate
9600 or 19 200, selectable by DIP switch
Start 1 bit
Data 8 bits
Parity None
Stop 1 bit
Table 7. 9-pin to 9-pin RS-232 connector layout
System Description Printer Description
Pin 2 - Rx (input) Pin 2- Tx (Output)
Pin 3 - Tx (Output) Pin 3 - Rx (Input)
Pin 4 - DTR (Output) Pin 4 - DTR (Input)
Pin 5 - Gnd Pin 5 - Gnd
Pin 6 - DSR (Input) Pin 6 - DSR (Output)
Pin 8 - CTS (Input) Pin 8 - RTS (Output)
Table 8. 25-pin to 25-pin RS-232 connector layout
System Description Printer Description
Pin 2 - Tx (Output) Pin 3 - Rx (Input)
Pin 3 - Rx (Input) Pin 2 - Tx (Output)
Pin 5 - CTS (Input) Pin 8 - RTS (Output)
Pin 6 - DSR (Input) Pin 6 - DSR (Output)
Pin 7 - Gnd Pin 5 - Gnd
Pin 20 - DTR (Output) Pin 4 - DTR (Input)
USB connector pin assignments
SureMark printers contain a USB port, if the USB feature is installed. This port is on
the interface card, accessible under the printer without removing printer covers.
Connection to the port can be with either the standard USB Type B connector,
which requires a 24-volt power brick, or with the powered USB connector, which
contains 24-volt power lines within the communications cable.
The standard USB Type B connector has the following pin functions:
August 24, 2004
Appendix B. Technical information 87
||
||
||
