v
If
you
try
to
set
an
MCT
value
out
of
its
defined
range,
it
is
set
to
the
closest
limit
(the
minimum
or
maximum
value)
or
rejected.
Microcode
tolerance
(MCT)
information
-
request
RS-232
Syntax:
ESC
S
n
or
X'1B;53;n'
where:
n
Microcode
tolerance
(MCT)
information
that
is
being
requested
Purpose:
To
enable
reading
MCT
information
from
EEPROM.
Remarks:
v
MCT
data
is
sent
over
the
serial
line
in
status
bytes
9
and
10.
See
Table
13
for
the
values
of
parameter
n.
v
MCT
write
command
values
that
are
out
of
range
cause
the
command
to
be
rejected.
(See
bit
7
of
“Status
byte
1”
on
page
166.)
Table
13.
MCT
command
definitions
DEC
HEX
MCT
Default
Min
Max
2
2
Matrix
of
user-defined
thermal
code
page
1
Byte
1:
Dot
row
width
Byte
2:
Dot
row
height
X'0A14'
(10x20)
X'0810'
X'1020'
(16x32)
3
3
Matrix
of
user-defined
thermal
code
page
2
Byte
1:
Dot
row
width
Byte
2:
Dot
row
height
X'0A14'
(10x20)
X'0810'
X'1020'
(16x32)
4
4
Matrix
of
user-defined
impact
code
page
1
Byte
1:
Half-dot
row
width
Byte
2:
Dot
row
height
X'0707'
(07x07)
X'0404'
X'1010'
(16x16)
5
5
Matrix
of
user-defined
impact
code
page
2
Byte
1:
Half-dot
row
width
Byte
2:
Dot
row
height
X'0707'
(07x07)
X'0404'
X'1010'
(16x16)
6-22
6-16
Reserved
-
ATTENTION:
Changing
these
values
might
damage
the
printer.
23
17
Matrix
of
user-defined
thermal
code
page
3
Byte
1:
Dot
row
width
Byte
2:
Dot
row
height
X'0A14'
(10x20)
X'0810'
X'1020'
(16x32)
24
18
Matrix
of
user-defined
thermal
code
page
4
Byte
1:
Dot
row
width
Byte
2:
Dot
row
height
X'0A14'
(10x20)
X'0810'
X'1020'
(16x32)
25-29
19-1D
Reserved
-
ATTENTION:
Changing
these
values
might
damage
the
printer.
August
24,
2004
Appendix
C.
RS-232
programming
information
123
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||||||
|||
|
||
||
|
|
||
|
|||
|
||
||
|
|
||
|
|||
|
||
||
|
|
||
|
|||
|
||
||
|
|
||
|
|||
|||
|
||
||
|
|
||
|
|||
|
||
||
|
|
||
|
|||
