n2 LSB of the logo width.
data The data to form the graphics image.
Purpose:
To print a small logo inline with characters.
Remarks:
v Thermal station only
v Rotate characters must be disabled
v n1 and n2 indicate the number of dots of the bit image in the horizontal
direction. The number of dots is calculated as n1×256+n2 (after first
converting n1 and n2 to decimal).
v The logo is 24 dot rows high. If printed in double-high mode, the logo will
be 48 rows high.
v The number of data bytes to form the image is figured by
{((n1×256+n2)−1)/8+1}×24.
v Like user-defined characters, if the image is only 14 dots wide, the last
two dots should be zero to complete the byte. When printed, the image
will be only 14 dots wide.
Select thermal paper
This command is supported only for Models TI3, TI4, TI8, TG3, TG4, TF6, and
TM6.
RS-232 Syntax:
GS ; n or X'1D 3B n'
where:
n
X'0' Disable two-color printing.
X'1' Enable color printing using print parameter set 1.
X'2' Enable color printing using print parameter set 2.
X'3' Enable color printing using print parameter set 2.
X'4'–X'FF'
Select the print parameters to be defined.
Purpose:
To enable two-color printing and select the print parameters that are best
suited for the paper selected.
Remarks:
v New parameters will be defined as new color papers become available.
v The speed of printing will change depending on the print parameters.
When print parameter set 1 is used, the print speed will be 15 lines per
second.
v This command setting is saved in nonvolatile memory.
Bar code commands
Bar code commands are valid in the thermal print station only.
August 24, 2004
144 SureMark Printers User’s Guide
|
|
|
|
