Table 2. Adjustment procedures using the Point-of-Sale Device Diagnostics
Procedure Tab
Character Alignment Adjustments
DI Front Load Adjustment Adjustments
Backlash Adjustment (Landscape) Adjustments
Engineering Use Only Read MCT
Firmware Update Firmware Update
Reset Thermal Print Head Statistics Reset Stats
Reset CR Motor Statistics Reset Stats
Reset Impact Print Head Statistics Reset Stats
Reset DI Motor Statistics Reset Stats
Reset Transport Motor Statistics Reset Stats
Using the reference/service diskettes (RS-485 or RS-232 printers)
1. Load the reference/service diskette. See the hardware service manual for your
system for reference/service diskette procedures.
2. Select Test Menu.
3. Select Run POS Device Tests for an RS-485 connection. Select RS232 4610
Printer Test for an RS-232 connection.
4. If another system is attached, select the system whose printer you want to
adjust. This is unnecessary when there is no other system attached.
5. Select Printer Utilities.
6. Select the adjustment you want to make from the menu.
v Print current adjustment values - see Figure 16 on page 37.
v Character alignment procedure - see Figure 16 on page 37.
v DI front load print line adjustment - see Figure 16 on page 37.
v Document landscape adjustment - see Figure 16 on page 37.
v Engineering use only
v Change 4610 Model Configuration
v Reset printer statistics
Note:
Because the first four adjustments affect only the document insert
station, they are not displayed as selectable options if the printer is a
single-station SureMark.
7. Follow the instructions that are printed on the printer or displayed on the screen.
8. Press S1 (Esc on the Enhanced A/N Keyboard) to return to the previous menu.
August 24, 2004
36 SureMark Printers User’s Guide
