3
-
10
Status
bytes
1-8.
See
the
descriptions
of
each
byte
in
the
sections
that
follow.
11
-
n
Either
5
bytes
of
additional
status
from
the
“Extended
address
command–request
printer
ID”
on
page
109
command,
or
up
to
246
bytes
of
user
data
that
can
include:
v
MICR
data
v
User
flash
data
v
MCT
data
Status
byte
1
Bit
Description
0
(LSB)
Command
complete
(immediate
command
and
flash
storage
commands).
Set
to
1
when
the
command
is
complete,
except
for
“Erase
flash
EPROM
sector”
on
page
121,
for
which
it
is
set
to
1
when
the
command
is
sent.
(See
bit
7
of
“Status
byte
3”
on
page
167.)
1
Cash
receipt
right
home
position.
Set
to
1
when
the
printhead
is
in
the
customer
receipt
right
home
position.
2
Left
home
position
Set
to
1
when
the
printhead
is
in
the
left
home
position.
3
Document
right
home
position.
Set
to
1
when
the
printhead
is
in
the
document
right
home
position.
4
Reserved.
Always
0.
5
Ribbon
cover
open.
Set
to
1
when
the
ribbon
cover
is
open.
6
Cash
receipt
print
error.
Paper
cover
is
open,
the
customer
receipt
station
is
out
of
paper,
or
the
cutter
is
jammed
in
the
closed
position.
7
(MSB)
Command
reject.
Status
byte
2
Bit
Description
0
(LSB)
Document
ready.
Set
to
0
when
the
document
insert
station
is
ready
for
printing.
This
occurs
when
both
document
sensors
detect
the
document
and
the
document
has
been
fed
to
the
first
print
position.
1
Document
present
under
the
front
sensor.
Set
to
0
when
a
document
is
under
the
front
document
sensor.
2
Document
present
under
the
top
sensor.
Set
to
0
when
a
document
is
under
the
top
document
sensor.
3
Reserved.
Always
equals
1.
4
Print
buffer
held.
Set
to
1
when
the
print
buffer
is
being
held.
Cleared
when
buffer
released.
5
Open
throat
position.
Set
to
1
when
the
printhead
is
in
the
open
throat
position.
6
Buffer
empty.
Set
to
1
when
no
print
data
and
no
commands
are
in
the
buffer.
7
(MSB)
Buffer
Full.
Set
when
only
1K
bytes
are
available
in
the
buffer.
August
24,
2004
166
SureMark
Printers
User’s
Guide
