Enable or disable upside-down printing
This command is supported only for Models TI3, TI4, TI8, TG3, TG4, TF6, and
TM6.
RS-232 Syntax:
ESC { n or X'1B 7B n'
where:
n Enables or disables upside-down printing.
X'00' Disable upside-down printing.
X'01' Enable upside-down printing.
Default:
n = 00
Purpose:
When the printer is wall-mounted, the front of the printer points up.
Therefore, the print data appears upside down when data is printed
normally. This command allows the data to be right-side up as it comes out
of the printer.
Remarks:
v When upside-down printing is enabled, the last line of data must be sent
to the print first.
v This command is valid only at the beginning of a print line.
Select character size for scalable fonts
This command is valid only for single-station SureMark Models TF6 and TM6, and
the thermal print station on Models TI3, TI4, TI8, TG3, and TG4.
RS-232 Syntax:
GS ! n or X'1D;21;n'
where:
n Defines the height and width of a character. The four least
significant bits (LSBs) specify the height and the four most
significant bits (MSBs) specify the width of the character. See
Table 16.
For example, if n=X'14' the scaled character will be twice the
defined width and five times the defined height.
Table 16. Width and height for scalable fonts
Four MSBs (in
hex)
Character Width Four LSBs (in
hex)
Character Height
0 As defined 0 As defined
1 2 × defined width 1 2 × defined height
2 3 × defined width 2 3 × defined height
3 4 × defined width 3 4 × defined height
4 5 × defined width 4 5 × defined height
5 6 × defined width 5 6 × defined height
6 7 × defined width 6 7 × defined height
7 8 × defined width 7 8 × defined height
August 24, 2004
142 SureMark Printers User’s Guide
