Note: If the CMA is preinstalled, the CMA would be secured by a strap to the cross bar during
transportation to avoid damage. This strap must be removed before installation.
Remove zip
tie before use
Cable
Figure 43. Cable management assembly
2. Verify the direction of the CMA arm as shown in the following gure.
66
IBM Storage ScaleSystem Utility Node: Hardware Planning and Installation Guide
